3.6kW Hybrid Solar Inverter 48V with MPPT and Lead-Acid Support

Brand Name:	SZSSTH
Model Number:	VICTOR NM-ECO-6.2KW PLUS
Price:	CN¥1262/pieces 1-499 pieces

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Input Voltage:

48V

Output Voltage:

220V 230V

Output Current:

Load

Output Frequency:

50Hz/60Hz

Output Type:

Single

Size:

420*350*110mm

Type:

DC/AC Inverters

Inverter Efficiency:

98%

Weight:

8.9kg

Product Name:

Hybrid Solar Inverter 3.6Kw

Inverter Type:

Hybrid Off Grid Solar Inverter

Controller Type:

MPPT Solar Controller

Communication:

WiFi/GPRS(Optional)

Battery Type:

Lead Acid \ Lithium \ Gel

Protection:

Overload

Rated Power:

3600VA

AC Voltage:

230VAC

Display:

LCD Display

Max PV Voltage:

360/500VDC

Certificate:

CE, ROHS

Warranty:

1 Year

Highlight:

3.6kW hybrid solar inverter

48V solar inverter with MPPT

hybrid inverter for lead-acid batteries

Product Description

VICTOR NM-ECO-6.2 KW PLUS – 48 V 3.6kW Hybrid Solar Inverter (On-/Off-Grid) with Lead-Acid Battery Support

Product Specifications

Attribute	Value
Input Voltage	48V
Output Voltage	220V 230V
Output Current	Load
Output Frequency	50Hz/60Hz
Output Type	Single
Size	420350110mm
Type	DC/AC Inverters
Inverter Efficiency	98%
Weight	8.9kg
Product name	Hybrid Solar Inverter 3.6Kw
Inverter type	Hybrid Off Grid Solar Inverter
Controller type	MPPT Solar Controller
Communication	WiFi/GPRS(Optional)
Battery type	Lead Acid \ Lithium \ Gel
Protection	Overload
Rated power	3600VA
AC Voltage	230VAC
Display	LCD Display
Max PV voltage	360/500VDC
Certificate	CE, ROHS
Warranty	1 year

Product Overview

The VICTOR NM-ECO-6.2 kW is a high-performance hybrid solar inverter, expertly engineered for both grid-connected and off-grid setups. With a rated power of 3600 VA (≈ 3600 W), this all-in-one inverter delivers pure sine wave output, built-in MPPT charging, and robust communications—designed for flexibility and reliability in modern solar installations.

Key Features

Pure Sine Wave Visual Design & High Efficiency

Delivers clean, symmetrical AC output with excellent load compatibility and safety for sensitive devices
Achieves a high 98% conversion efficiency, maximizing energy usage

Native Hybrid Operation & Battery Flexibility

Supports both on-grid and off-grid operation
Works seamlessly with lead-acid, lithium, and gel battery types
Includes a built-in lithium battery activation feature for hassle-free startup

Built-In MPPT Solar Charge Controller

Integrated MPPT solar controller handles up to 120 A
PV input capacity up to 6500 W with wide MPPT voltage range of 60-500 VDC
Start-up voltage is 90 VDC, with maximum PV voltage of 500 VDC for grid-tie mode

Multi-Mode Functionality

Supports versatile operating preferences: inverter works with or without a battery
Features one-key factory reset and dual communication ports for Wi-Fi, GPRS, and battery management

Intelligent Dual Load Output

Offers a dual load output system for power allocation between main and secondary loads
Protects critical loads during low battery situations by disabling non-essential circuits

Rugged & Safe Design

Includes a built-in anti-dust kit for durability in harsh environments
Features comprehensive protection: overload, temperature, and short-circuit protection

Convenient Monitoring & Control

Equipped with LCD display for real-time system status
Optional Wi-Fi/GPRS connectivity enables remote monitoring via smartphones or PCs

Technical Specifications

MODEL	VICTOR NM-ECO-3.6KWPLUS	VICTOR NM-ECO-4.2KWPLUS	VICTOR NM-ECO-6.2KWPLUS
Phase	1-phase
Maximum PV Input Power	6200W	6200W	6500W
Rated Output Power	3500W/3600VA	4200W/4200VA	6200W/6200VA
Maximum Solar Charging Current	120A	140A	120A
GRID-TIE OPERATION
PV INPUT(DC)
Nominal DC Voltage/Maximum DC Voltage	360/500VDC
Start-up Voltage /Initial Feeding Voltage	60VDC/90VDC
MPPT Voltage Range	60-450VDC
Maximum Input Current	1/18A	1/22A
