4.2kW 24V Hybrid Solar Inverter with MPPT Charge Controller

Brand Name:	SZSSTH
Model Number:	VICTOR NM-ECO-4.2KW PLUS
Price:	CN¥1,558.16/pieces 1-499 pieces

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Input Voltage:

24V

Output Voltage:

220V 230V

Output Current:

Load

Output Frequency:

50Hz/60Hz

Output Type:

Single

Size:

420*350*110mm

Type:

DC/AC Inverters

Inverter Efficiency:

98%

Weight:

8kg

Product Name:

Hybrid Solar Inverter 4.2Kw

Inverter Type:

Hybrid Off Grid Solar Inverter

Controller Type:

MPPT Solar Controller

Communication:

WiFi/GPRS(Optional)

Battery Type:

Lead Acid \ Lithium \ Gel

Protection:

Overload

Rated Power:

4200VA

AC Voltage:

230VAC

Display:

LCD Display

Max PV Voltage:

500V

Certificate:

CE, ROHS

Warranty:

1 Year

Highlight:

24V hybrid solar inverter

4.2kW solar inverter with MPPT

hybrid inverter with charge controller

Product Description

S-SERIES-4.2 kW PLUS – 24 V Hybrid Solar Inverter with MPPT

Product Specifications

Attribute	Value
Input Voltage	24V
Output Voltage	220V 230V
Output Current	Load
Output Frequency	50Hz/60Hz
Output Type	Single
Size	420350110mm
Type	DC/AC Inverters
Inverter Efficiency	98%
Weight	8kg
Product name	Hybrid Solar Inverter 4.2Kw
Inverter type	Hybrid Off Grid Solar Inverter
Controller type	MPPT Solar Controller
Communication	WiFi/GPRS(Optional)
Battery type	Lead Acid \ Lithium \ Gel
Protection	Overload
Rated power	4200VA
AC Voltage	230VAC
Display	LCD Display
Max PV voltage	500V
Certificate	CE, ROHS
Warranty	1 year

Product Overview

The S-SERIES-4.2 kW PLUS is a versatile 24V hybrid solar inverter that seamlessly supports both off-grid and on-grid solar systems. Featuring a built-in MPPT charge controller and pure sine wave output, this all-in-one unit suits modern energy needs—ideal for homes, cabins, and small-scale renewable setups.

Key Features

Pure Sine Wave with High Power Efficiency - Delivers clean, grid-quality pure sine wave AC output with a 98% conversion efficiency, ensuring safe and reliable operation for sensitive devices.
Robust MPPT Solar Charging - Equipped with a high-capacity MPPT controller offering up to 140A solar charge current, supporting a maximum PV input power of 6200W. The wide PV voltage range of 60-500VDC ensures optimal solar energy harvesting under varying conditions.
Flexible Operation without Battery Required - Capable of running standalone—no battery needed—this inverter delivers continuous power even during maintenance or battery absence.
Smart Connectivity & User-Friendly Display - Includes an LCD display for real-time system monitoring. Optional WiFi and GPRS modules enable remote access, while dual ports support battery communication and system control.
Easy Setup & Smart Controls - Features a one-click factory reset and automatic lithium battery activation, simplifying configuration and promoting longevity.
Durable Design for Harsh Environments - Built with an integrated anti-dust kit, this inverter is designed to withstand rugged environments.
Dual Output Capability - Supports dual output modes: a primary full-power output and a secondary output (e.g., smaller loads) with independent cutoff and return voltage settings for optimized load management.

Technical Specifications

MODEL	SP-2200	8P-3200	SP-4200	8P-4200	8P-7000
Rated Power	2200VA/1800W	3200VA/3000W	4200VA/3800W	4200VA/3800W	7000VA/6200W
INPUT
Voltage	230VAC
Selectable Voltage Range	170-280VAC(for personal computers) 90-280VAC(for home appliances)
Frequency Range	50Hz/60Hz(Autosensing)
OUTPUT
AC Voltage Regulation(Batt.Mode)	230VAC±5%
Surge power	4400VA	6400VA	8400VA	8400VA	14000VA
Transfer Time	10ms(for personal computers) 20ms(for home appliances)
Waveform	Pure SineWave
BATTERY & AC CHARGER
Battery Voltage	12VDC	24VDC	24VDC	48VDC	48VDC
Floating Charge Voltage	13.5VDC	27VDC	27VDC	54VDC	54VDC
Overcharge Protection	15.5VDC	31VDC	31VDC	61VDC	61VDC
Maximum charge current	60A	80A	60A	80A	-
SOLAR CHARGER
MAX.PV Array Power	2000W	3000W	6000W	-	-
MPPT Range@Operating Voltage	55-450VDC
Maximum PV Array Open Circuit Voltage	450VDC
Maximum Charging Current	80A	110A	80A	110A	-
Maximum Efficiency	98%
PHYSICAL
Dimension.DWH(mm)	40528698mm	423290100mm	423290105mm	-	-
Net Weight(kgs)	4.5kg	5.0kg	6.8kg	6.9kg	7.5kg
Communication Interface	RS 232/RS 485(Standard) WIFI(Optional)
OPERATING ENVIRONMENT
Humidity	5%to 95%Relative Humidity(Non-condensing)
Operating Temperature	-10°C to 55°C
Storage Temperature	-15°C to 60°C
