Smart Solar Charge Controller Dc 12v 24v 36v 48v 30a Mppt Solar Regulator

Smart Solar Charge Controller Dc 12v 24v 36v 48v 30a Mppt Solar Regulator

Brand Name:	SZSSTH
Model Number:	MPS 30A
MOQ:	1 pieces
Price:	$63-68/pieces
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	5000 piece/month

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

CE RHOS BSI

Document:

12V~48V MPPT solar charge c...er.pdf

Type:

MPPT

Work Time (h):

24H

Rated Voltage:

12v 24v 36v 48v

Maximum Current:

30A

MPPT Efficiency:

99%

Size:

210*150*80mm

Weight:

1.45kg

Packaging Details:

color box

Highlight:

Smart Solar Charge Controller

30a Mppt Solar Regulator

Dc 12v Mppt Solar Regulator

Product Description

MPPT Solar Charge Controller – Efficient, Intelligent, and Versatile

Harness the Sun’s Power with Advanced MPPT Technology

Upgrade your solar energy system with our high-efficiency MPPT Solar Charge Controller, designed to maximize power generation with 98% efficiency. Compatible with 12V/24V/36V/48V systems, it ensures optimal performance for a wide range of applications, from residential to industrial setups.

Key Features

Wide Voltage Range – Supports 18-150VDC input, adaptable to various solar panel configurations.
High-Efficiency Charging – MPPT technology extracts maximum power from your solar panels.
Intelligent Temperature Control – Built-in cooling fan ensures stable operation under heavy loads.
User-Friendly Interface – HD LCD display with clear indicators for solar charging, battery status, and DC load.
Multiple Protections – Comprehensive safeguards for overvoltage, overheating, and short circuits.
Remote Monitoring – Supports PC software, WiFi module, and APP cloud monitoring for real-time tracking.

Product Name		MPS 30A	MPS 40A	MPS 60A	MPS 80A	MPS 100A
System Rated Voltage		12/24/36/48VDC or Self-identification
Controller operating voltage range		12-64V
Lead-acid battery type		Maintenance-free(default) /Colloid /Liquid /Custom
Lithium battery type		Lithium Iron Phosphate /Ternary Lithium /Custom
Rated charging current		30A	40A	60A	80A	100A
Rated charging power		390W /12V	540W/12V	800W/12V	1040W/12V	1300W/12V
			1080W/24V	1600W/24V	2080W/24V	2600W/24V
			1620W/36V	2400W/36V	3120W/36V	3900W/36V
			2160W/48V	3200W/48V	4160W/48V	5200W/48V
Maximum open ccircuit voltage of photovoltaic modules		150V (under the lowest temperature condition) 138V (under 25℃ condition)

Maximum power point operating voltage range	12V System	20~150VDC
	24V System	36~150VDC
	36V System	48~150VDC
	48V System	64~150VDC
Tracking efficiency		≥99.5%
Maximum conversion efficiency		97.50%
Temperature compensation coefficient		-3mV/ ℃ /2V
Statuc loss		350mA/12V: 170mA/24V: 85mA/48V			700mA/12V: 350mA/24V: 175mA/48V
DC Load output voltage		Can be turned on in 12V/24V Moode
DC load rated output current		40A
DC load output control		Normally open ormally closed mode /Time control mode /Light control mode
Protective function		PV input reverse connection protection
		Battery input reverse connection protection
		Battery overcharge protection
		Battery under voltage protection
		Battery over tempearature protection
		Machine over temperature protection
Colling Method		Wind cooling
Way of communication		RS485
LDC Backlight time		Default 60S, Backlight mode cab be set
Environmental parameters
Working environment temperature range		-20℃ ~＋50℃
Storage temperature range		-40℃ ~＋70℃
Relative humidity range		0 ~ 90%RH
Mechanical parameters
Dimensions		21015080mm	219300110mm	219300110mm	275363109mm	275363109mm
Recommened wiring		9AWG/6mm²	7AWG/6mm²	6AWG/6mm²	4AWG/6mm²	2AWG/6mm²
Net weight		1.45kg	2.94kg	2.94kg	4.56kg	4.56kg

Smart Solar Charge Controller Dc 12v 24v 36v 48v 30a Mppt Solar Regulator 0

Smart Solar Charge Controller Dc 12v 24v 36v 48v 30a Mppt Solar Regulator 2
