Highlight:
                                                                                                                                                                                                                                                                                                                1600W Peak Off Grid Power Inverter, Pure Sine Wave Power Inverter, 12V 24V 48V 60V Power Inverter


Output Type:	Single	Output Frequency:	50Hz/60Hz
Output Waveform:	Prue Sine Wave(THD<3%)	Rated Power:	800W 1000W 1300W
Peak Power:	1600W 2000W 2600W	Display:	LED Screen
Certificate:	CE ROHS FCC KC	Protection:	Overload

Output Type:	Single
Output Frequency:	50Hz/60Hz
Output Waveform:	Prue Sine Wave(THD<3%)
Rated Power:	800W 1000W 1300W
Peak Power:	1600W 2000W 2600W
Display:	LED Screen
Certificate:	CE ROHS FCC KC
Protection:	Overload

1600W Peak 12V 24V 48V 60V DC to AC Off Grid Power Inverter with Pure Sine Wave Output

High-Efficiency & Reliable Power Solution – S23 Pure Sine Wave Inverter

Key Features:

Pure Sine Wave Output (THD <3%) – Ensures clean and stable power for sensitive electronics like refrigerators, air conditioners, and medical equipment.
Smart Digital Control – Adjustable output voltage (100V-240VAC) and frequency (50Hz/60Hz), compatible with global power standards.
High Efficiency (Up to 94%) – Low energy loss with standby current <0.5A, ideal for solar/battery systems.
Advanced Safety Protections – Overload, over-temperature, high/low voltage cut-off, and reverse polarity protection.
LED Status Display – Real-time monitoring of battery level (25%-100%) and load status for easy operation.

Wide Applications:

Home & Office: Refrigerators, rice cookers, TVs, laptops, and projectors.
Outdoor & Emergency: Camping, RVs, car appliances, and power backup.
Industrial Tools: Electric drills, pumps, and other high-power devices (2000W peak).

Technical Specifications:

Input Voltage: 12V/24V/48V/60V (Wide range: 10.5V-60V DC).
Output Voltage: 110V/220V pure sine wave (switchable).
Rated Power: 1000W continuous, 2000W peak (150% surge capacity).

Package Includes:

Battery cables (53cm) with clamps for quick installation.

Certifications:

CE, FCC, LVD, RoHS compliant for safety and reliability.

Choose S23 – Power Anywhere, Anytime with Confidence!

Output	Model	HIP-1000(New)
	Power	0%-100 status (continuous use) ----120 10S -150% 1S
	Voltage Frequency	Factory setting: 220VAC±3V By setting:200/220/230/240VAC		Factory setting: 110VAC±3V By setting Setting:100/110/115/120VAC
		50±0.5Hz		60±0.5Hz
	Waveform	Pure sine wave at rated power input (THD<3)
	Protection	Output short-circuit protection, overload protection, overload protection, over-temperature protection
Input	Battery Voltage		10.5V-15V	20V-30V	40V-60V
	efficiency		92%	93%	94%
		HIP-1000amps	10 3A	54A	27A
	Static electric current	<0.5A
	Protection	Over-current protection, reverse battery connection protection (built-in fuse), low battery voltage warning and power-on protection.Power on protection
