Lightweight 24V DC to 110V 220V 230V Pure Sine Wave Solar Hybrid Inverter with MPPT Solar Controller

Lightweight 24V DC to 110V 220V 230V Pure Sine Wave Solar Hybrid Inverter with MPPT Solar Controller

Brand Name:	SZSSTH
Model Number:	SUF3000S4A1
MOQ:	1PCS
Price:	$192.00-$208.00/PCS
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	100000PCS/MONTH

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

CE RHOS BSI

Document:

3K&5KW Off-grid-Inverter.pdf

Weight:

7.5kg

Inverter Type:

Hybrid Off Grid Solar Inverter

Controller Type:

MPPT Solar Controller

Communication:

WiFi/GPRS(Optional)

Battery Type:

Lead Acid \ Lithium

Protection:

Overload

Rated Power:

3.5KW

Certificate:

CE, ROHS

Warranty:

1 Year

Packaging Details:

Carton Box

Highlight:

24V Solar Hybrid Inverter

220V Solar Hybrid Inverter

MPPT Solar Hybrid Inverter

Product Description

Product Description: 3K&5KW Off-Grid Inverter

Key Features:

Compatible with most common low-voltage batteries (lead-acid and lithium batteries).
The 5K model supports parallel operation for up to 6 units.
Maximum charging current of up to 130A.
Equipped with an LCD screen for secure user interaction.
Remote monitoring via mobile app (Wi-Fi); seamless integration with BMS.
Intelligent fan cooling design for optimal performance.

Technical Specifications:

Parameter	3KW Model	5KW Model
Battery Voltage	24VAC	48VAC
Nominal Power (W)	3000	6000
Peak Efficiency	93%	93%
Waveform	Pure Sine Wave	Pure Sine Wave
Max PV Array Power (W)	4000	6000
Max Solar Charge Current (A)	150	80
AC Voltage Regulation	230VAC ± 3% (50/60Hz)	230VAC ± 3% (50/60Hz)
Protection Rating	IP54	IP54
Operating Temperature	0°C to 30°C	0°C to 30°C

Advanced Protection & Safety:

PV Over Voltage/Current Protection
Battery Over Voltage/Current Protection
Output Short Circuit & Over Voltage Protection
Type II DC Surge Protection

Design & Connectivity:

Compact dimensions: 300 × 450 × 110.5 mm (W×D×H).
Lightweight: 2.5 kg (3KW) / 3 kg (5KW).
Multiple interfaces: USB, Wi-Fi, GPRS, CAN, and dry-contact communication options.

Ideal For: Off-grid solar systems, residential use, and remote applications requiring reliable power with advanced monitoring capabilities.

Why Choose Us?

High efficiency and durable design.
User-friendly interface with real-time monitoring.
Robust safety features for uninterrupted performance.

Upgrade your energy independence with our cutting-edge off-grid inverters!

SUF3000S4A1	SUF5000S4A1
BatteyInput
Battery Type	Li-lon/Lead-acid	Li-lon/Lead-acid
BatteryVoltage	24Vdc	48Vdc
Inverter Output
Nominal Power(W)	3000	5000
Nominal Apparent Power (VA)	3000	5000
Paralll Capacity	No	Yes.9 units maximum
AC Voltage Regulation (Battery Mode)	230Vac±5%@50/60Hz	230Vac±5%@50/60Hz
Surge Power (VA)	6000	10000
Eficiency (peak)	93%	93%
Waveform	Pure sine wave	Pure sine wave
Transfer Time	10ms (for personal computers), 15ms (for home appliances)
SolerCharge
Max.PV Array Power (W)	4000	6000
		6000
MPPT Range @OperatingVoltage	120Vdc-430Vdc	120Vdc-430Vdc
Number of Independent MPP Trackers	1	1
Number of Strings Per MPPT	1	1
Max,Input Current Per MPPT(A)	16	18
Max.PV Array Open Circuit Voltage (V)	500Vdc	500Vd
Max Solar Charge Current (A)	120	80
Ac Charger
Max.AC Charge Current(A)	120	80
AC Input Voltage (V)	230Vac	230Vac
Voltage Range (V)	170-280Vac (For PersonalComputers); 90-280 Vac(For Home Appliances)
Frequency Range(Hz)	50/60	50/60
General
UserInterface	APP+LCD Display+LED
Communication	USB,Optional:Wi-Fi,4G,GPRS,RS485/CAN,Dry-contact
Ingress Protection Rating	IP54	IP54
Dimension (WHD mm)	300450110.5	300450110.5
Weight (kg)	7.5 8
Relative Humidity	20%~95%	20%~95%
Max.Operating Altitude (m)	2000m, >1000m derating	2000m,>1000m derating
Operating Temperature (°C)	0~50	0~50
Storage Temperature (°C)	[-15~60]	[-15~60]
Protection
PV Over VoltageProtection	Yes
PV Over Current Protection	Yes
Battery Over Voltage Protection	Yes
Battery Over Current Protection	Yes
AC Surge Protection	Type II
Output OverCurrentProtection	Yes
Output Short Circuit Protection	Yes
Output OverVoltage Protection	Yes
